Paramtents
Frequency interval 25MHZ
Earphone load impedance >16Ω
Type stereo in ear monitor
Channel one channel
Packging & Delivery
Min Order1 piece
Briefing
Detailed
RECEIVER | |
Bandwidth: | 555-580 MHZ |
Frequency interval: | 25MHz |
Receiving mode: | Single tuning |
Audio response: | 80Hz~15KHz |
Output power ( 32Ω ) | 2x35mW@1KHz |
Earphone load impedance: | >16Ω |
Output jack: | 3.5mm sound earphone socket |
Oscillate mode: | PLLPhase locked frequency synthesis |
Power box: | ( AA )Two batteries |
LAUNCHER | |
Bandwidth: | 555-580 MHZ |
Frequency interval: | 25MHZ |
Transmit output power: | 100MW( 50Ω) |
Audio input: | XLR and 6.3mm composite socket |
Headphone output: | 6.3mm stereo socketvolume adiustable |
Earphone load impedance: | >16Ω |
Current consumption: | DC 12V/500mA |
Antenna output base: | TNC socket (50 Ω) |
