If you want the speakers to emit good music, the placement of the speakers is very important, which is also the core content of the bar sound design. Let's briefly take a look at the speaker placement methods commonly used in the bar.

There are two commonly used speaker placement methods in bars now: ① distributed type ② centralized type.

How to place the subwoofer?

The correct answer to this question is to place the subwoofer in a row as close to the dance floor as possible. If there is difficulty, a circular sector can also be used, but it is absolutely impossible to have a circle or two boxes facing each other. Build a hard wall one meter behind the subwoofer, higher than the speaker, and you will find that the bass power seems to be doubled, and it is clear and powerful. Now some bars often hang suspended speakers in a circle above the dance floor for the beauty of bar design. Although this is very beautiful, it is not very practical because we use speakers to play music, not for decoration.

Recently, Sinbosen received a bar speaker project from a client.

His site size is 600m², 7 meter height.

There are the main stage and 3 VIP areas all around, of which there are two wall pillars in the VIP area directly opposite the main stage. In the middle is the T stage, and the two sides of the T stage are the dance floor.

We recommended a speaker system and layout for him (distributed placement and bass boxes placed in rows close to the dance floor), the speakers of this system are Sinbosen's latest speakers, and the materials and sound quality are top-notch.

The position of this set of speakers :
① On both sides of the main stage, six K2 3-way 12 "speakers are suspended to form a horizontal array as the main speakers, which makes the scene feel very real.

② Due to the distribution of wall columns near the booth, the sound field will be affected, and the block area is the key area of consumption, the effect must be guaranteed. Each booth is understood as a private room without walls, with a separate layout for the speakers. So a total of 12 A15wide speakers were finally hoisted as sound complement monitoring. That is, 3 booth areas (against the wall) each with 4 A15 speakers ceiling.

③Subwoofer is mainly to expand the full frequency speaker of the ultra low part. To measure whether a pub atmosphere enthusiasm, ultra-low speakers play a decisive role, quality higher requirements, of course. So we put four double 18-inch, 1,000-watt, high-powered KS28 subwoofers under the main stage, and eight other KS28 subwoofers scattered around, a total of 12.
